Marine and boat water tank sizes and drawings

Part No.	Capacity	Length	Width	Depth
W-359	56	90	17.5	12
W-360	56	90	17.5	12
W-361	16	15	25.25	13
W-363	35	66	15.5	9.81
W-365	25	59	13.5	7.5
W-366	15	36	13.5	7.5
W-366	8	19.5	13.5	7.5
W-366	12	24	15	12

Rectangle Shaped Marine Water Tanks

Part No.	Capacity	Length	Width	Depth	Drawings
L-1	10	18	16	8
L-2	12	24	16	8
L-3	15	30	16	8
L-4	20	36	16	8
L-5	25	48	16	8
W-1	40	58	14	12
W-101	100	50	40	12
W-108	145	50	31.25	22
W-12	53	30.25	24.5	17.25
W-17	40	41	15.25	15.5
W-2	27	35	15	13
W-20	25	42	16	10
W-201	25	52.5	12	10.75
W-202	35	37	20	12
W-204	40	42.25	27	9.5
W-205	38	58.5	16.125	10
W-207	28	35.25	15	13
W-208	50	57	36	6
W-209	19	36	15.5	8
W-210	10	24	15.5	8
W-212	52	58	24	9
W-213	72	34.5	23	21.5
W-214	98	52	26	17
W-218	95	41	25.25	22
W-22	35	31.5	19.5	14.75
W-220	68	42.5	39	9.5
W-221	100	36	27.5	23.5
W-223	65	34	24	18.5
W-225	28	34.25	17.5	12
W-226	40	58	21	8
W-227	38	71.5	13	10
W-228	50	64	32	6
W-230	97	67	48	7
W-231	41	50	19	10
W-233	30	35.5	19	10.75
W-234	34	48	21	8
W-236	32	50.5	20	8
W-237	33	30	16	16
W-238	128	64.5	40	11.5
W-239	140	64.5	43.5	11.5
W-24	45	40	19	16
W-241	65	60	22	11.5
W-244	30	29.75	25.75	9.5
W-245	9	17.625	15.625	8.25
W-248	40	31	26	11.75	Request
W-249	50	26	21.5	21	Request
W-25	45	48	28	8	Request
W-250	44	38	17	16	Request
W-251	80	59	49.5	7	Request
W-254	30	33	20	11	Request
W-257	39	55	28	6.25	Request
W-259	39	28.375	18	17.5	Request
W-26	8	19.25	13	9.5	Request
W-264	45	64	24	7.5	Request
W-266	38	47	17	12.125	Request
W-268	22	35	14	12	Request
W-27	15	22.25	13	13	Request
W-270	40	60	18	9.375	Request
W-271	50	68	13.5	13.5	Request
W-272	142	60	43	13.75	Request
W-275	50	45	26	10	Request
W-276	60	53.5	21	13	Request
W-277	60	57	28	9	Request
W-279	48	72	20	8	Request
W-28	13	30	14	8.25	Request
W-280	30	44	14	12	Request
W-282	16	30.125	17.25	8	Request
W-284	40	41	21	11	Request
W-285	27	44	17	9	Request
W-289	50	48	18	14.5	Request
W-291	40	31.75	28	11.25	Request
W-292	30	34.5	18	12	Request
W-293	40	34	16	17	Request
W-294	10	40	25	9.25	Request
W-295	40	54	23.5	8	Request
W-296	40	41	21	11	Request
W-3	38	48.5	14	13	Request
W-30	30	32	20	12	Request
W-300	60	48	21.5	14.5	Request
W-302	55	51	21	13	Request
W-304	25	25	21	12	Request
W-305	54	55	28	8.375	Request
W-306	8	36	16	4	Request
W-307	40	33	22.5	13.5	Request
W-308	107	94	27	9.75	Request
W-309	44	60	31	5.75	Request
W-31	27	21	18	18	Request
W-310	105	92	27.5	10	Request
W-313	40	38	25	11	Request
W-314	40	60	18	9.375	Request
W-315	93	71	27	11.5	Request
W-316	35	33	28	9	Request
W-318	50	51	28	8.375	Request
W-32	30	42	28	6.5	Request
W-320	21	21	21	12.5	Request
W-323	29	25	24	12	Request
W-324	38	41.5	17.75	12.5	Request
W-327	15	23	16	11	Request
W-328	15	48.5	10.75	7.875	Request
W-33	10	31	15.5	6	Request
W-330	50	54.75	27	8	Request
W-331	62	50	32	9	Request
W-332	33	42	21.5	9	Request
W-335	27	42.5	17.5	9	Request
W-338	30	45.5	22	7.75	Request
W-34	74	65	20.75	13	Request
W-345	163	65	30.5	19.25	Request
W-347	132	65	38	12.5	Request
W-35	45	42	20	13	Request
W-354	6	17	12	8	Request
W-355	15	17.75	14.75	14.75	Request
W-362	65	39.75	23.75	16.25	Request
W-368	20	24.5	15.5	13.5	Request
W-369	6	16	12	8	Request
W-37	60	70	26	8	Request
W-371	21	29	20	9	Request
W-372	188	62	40	17.5	Request
W-373	32	64	24	5.25	Request
W-376	8	54	6	7	Request
W-38	44	42	26.5	9.5	Request
W-4	55	60	20.5	11	Request
W-45	25	27	20	12	Request
W-48	41	60	28	6	Request
W-49	3	16	7.5	6.5	Request
W-51	20	21	17	14	Request
W-53	10	24	14.5	7.5	Request
W-55	28	52	12	11	Request
W-56	160	64.75	43	13.75	Request
W-59	60	79.25	15.75	11.5	Request
W-60	105	79.25	27	11.5	Request
W-63	105	46.5	33	16	Request
W-68	103	59.25	23.625	17.75	Request
W-69	145	69.75	44	11	Request
W-74	60	50	18	16	Request
W-75	35	69	11	11	Request
W-76	57	48	24	12	Request
W-77	5	15.5	15.5	5	Request
W-79	47	48	19.75	12	Request
W-80	20	24	17.75	12	Request
W-81	20	33.25	17.25	8.75	Request
W-84	68	48.5	26	13	Request
W-85	25	34	17.5	11	Request
W-88	105	48	24	21.5	Request
W-95	20	30	18	9	Request
W-96	40	54	20	9	Request
W-97	15	33	21.5	5.75	Request
W-380	43	99	13.75	7.5	Request
W-403	55	45	23	12.75	Request
W-364	2	9.75	9.75	6	Request

Wedge Shaped Marine Water Tanks

Part No.	Capacity	Length	Width	Depth	Drawings
W-211	72	61.75	24	13	Request
W-215	100	78	26	14	Request
W-224	88	73.75	24.25	12.75	Request
W-273	70	73.75	24.25	10.75	Request
W-274	65	69	24.25	10.75	Request
W-281	81	70	26.75	11.75	Request
W-303	97	73	24.75	14	Request
W-349	82	48	40.5	11	Request
W-350	108	76	40	10	Request
W-353	93	59	36.5	11.375	Request
W-358	8	19.75	17.75	8	Request
W-374	107	76	38.5	10.125	Request
W-375	17	24.5	22	9	Request
W-93	150	67.5	40.5	14.25	Request
W-99	105	60	40.5	11.5	Request
W-378	110	57	32	16	Request

Learn more about One Clarion’s marine water tanks. We make them in just about any size or shape, and will customize the fitting size and location to fit your boat. Learn more!
