Sludge Dewatering Tubes

sludge dewatering


Sludge Filtration

Geotube Sludge Dewatering

Sludge filtration is a crucial component of removing sediment, debris, and material from the bottom of lakes, rivers, harbors, marinas, and other bodies of water. Our geotube sludge dewatering tubes are designed to help you contain and dewater sludge in excess of 50%, making the process more cost-effective than belt presses or other methods of dewatering.

Fabricated from a specially engineered textile, our geotubes keep fine solids inside the tube or bag, while still allowing water to flow through the durable fabric. We use high strength seaming techniques with filling ports or other provisions to ensure success for your site. These geotube dewatering containers are designed to optimize the solids retention and effluent discharge making them highly efficient and environmental friendly. We have a variety of sizes to meet your needs. Cities and counties can stay compliant while dredging pollution and sludge with our high volume, low cost sludge dewatering solution.

Our friendly staff is here to help you get the exact product you need!


Call us now! 1-863-261-8388
or Contact us for additional information.



Sludge Filtration Features and Benefits

Filtration Features


  • Fabric: High Strength Geotextile
  • Length: up to 200 ft.
  • Circumference: up to 120 ft.
  • Effectively Filters out Sludge, Silt, Sediment, and Waste
  • Easy removal and disposal of solids
  • Reliable in all weather conditions
  • Reduces risks in operational safety

Filtration Benefits


  • Designed for Large or Small Sludge Filtration Projects
  • High Strength Woven Geotextile Fabrics
  • Large Sizes Available
  • Cost effective and low maintenance
  • Efficient, versatile and environmental friendly

For more information, download our Geotextile Dewatering Tubes (pdf).



What is Sludge Filtration?

Sludge filtration is used in environmental remediation for water dredging in contaminated areas. Sludge and sediment need to be carefully contained in lakes, rivers or harbors so it doesn't spread to the air or other parts of the body of water. Sludge dewatering can also be used in marinas and other bodies of water to improve navigation and make waterways more accessible for ships and vessels. Containing sludge and silt, while filtering water helps keeps your city or county in compliance.


How Sludge Filtration Tubes Work

1. Filling: Sludge or silt is pumped into the dewatering tube. Solids bind together, allowing the water or liquid to separate out.

2. Dewatering: Clear effluent water drains from tube, leaving 99% of solids in the tube. Clear filtered water can then be recirculated in the system.

3. Consolidation: Solids remain in the bag. When tube is full, contents are deposited in landfill or removed and applied to land when appropriate.


Have more questions about our bag filter for sludge dewatering? We can help. For more information call us at 1-863-445-9623 or Contact Us through our webform.

Filtration Tube Specifications

Property Value Additional Notes
Length 22', 50', 57', and 100' Other Lengths by Special Order
Circumference 22.5', 30', 45', 60', 120' -
Filling Port Spacing 1 - 3 ports Average One Port Every 50' of Length

*Custom sizing also available.


Size Per Tube (Circumference) Tube Volume(cy/tube) Silts & Organics Tube Volume(cy/tube) Sand & Minerals
22.5 ft. 20 - 25 20 - 25
30 ft. 99 85
45 ft. 204 172
45 ft. 367 309
60 ft. 553 464
120 ft. 1460 1185

Sludge Filtration Bags or Tubes

Needing to remove contaminated dredged material? Our sludge filtration bags or tubes provide a durable, cost-effective way to remove and dispose of contaminated dredging sludge. Geotube sludge dewatering helps to keep contaminants out of city and county waterways by efficiently filtering and trapping dredging solids, so you can easily dispose of them. Available in a variety of sizes for large-scale or smaller applications, our specially engineered geotextile dewatering bags effectively contain even hazardous materials, reducing volume and saving you thousands in disposal costs. These prefabricated containers are engineered with high-strength, quality-seaming techniques to give you an efficient and environmentally friendly solution for your dewatering applications. When your city and county needs to remove silt or sediment from the bottom of rivers, lakes or other water bodies, sludge filtration bags are an economical, effective tool.

Looking for silt curtains, dewatering solutions or other municipal applications? Visit our One Clarion products applications overview page or check out our dewatering products overview page for more information.


Have more questions about our bag filter for sludge dewatering? We can help. For more information call us at 1-863-445-9623 or Contact Us through our webform.
