Spill Berms

yellow foam wall berm

Spill Berms

Aluminum Angle, Foam Wall, and Combination Berms

Spill berms offer secondary spill containment for tanks, vehicles, and machinery used throughout cities and counties. Easily set up and transported, the spill berms are reusable between city areas and departments.


Secondary containment berms can handle fuels, chemicals, contaminated water, and oils, depending on the material. Spill berms are available in the following fabrics:


  • Copolymer-2000
  • PVC
  • Other materials available

In addition to the sizes below, customization is available for all spill berm types, depending on the application.

Our friendly staff is here to help you get the exact product you need!


Call us now! 1-863-261-8388
or Contact us for additional information.


Secondary Containment Berms

aluminum angle berm

Aluminum Angle Berm

foam wall spill berm

Foam Wall Berm

combination containment berm

Combination Drive Through Berm

Concrete Washout Area Berm

Concrete Washout Area Berm

Aluminum Angle Berms

Aluminum angle berms have a containment berm design best suited for extended or semi-permanent containment. Once in place, the L-shaped aluminum brackets created a 1-foot barrier around tanks, drums, or other machinery. The sturdy shape ensures long-term relief from spill contamination, even outdoors in direct UV exposure.


Part Number Dimensions ft. (m) Containment Capacity gal. (L) Weight lbs. (kg)/th>
8250 6 x 4 x 1 (1.8 x 1.2 x .3) 179 (677.6) 21 (9.5)
8251 6 x 6 x 1 (1.8 x 1.8 x .3) 269 (1018.3) 26 (11.8)
8252 10 x 10 x 1 (3 x 3 x .3) 748 (2831.5) 52 (23.6)
8270 20 x 10 x 1 (6.1 x 3 x .3) 1496 (5663) 88 (39.9)
8271 30 x 10 x 1 (9.1 x 3 x .3) 2244 (8494.5) 124 (56.2)
8272 40 x 10 x 1 (12.2 x 3 x .3) 2992 (11326) 160 (72.6)

Foam Wall Berms

The foam wall portable spill berms provide quick, temporary containment for small leaks and wash water. Equipment and machinery easily moves over the 2-inch or 4-inch foam wall. The shorter walls provides smaller containment capacity than an aluminum angle berm, however, because of their low profile containment berm design, our spill berms easily roll up for transportation between city sites.


Part # Dimensions ft. (m) Containment Capacity gal. (L) Weight lbs. (kg)
8385 6 x 4 x .2 (1.8 x 1.2 x .1) 25 (94.6) 24 (10.9)
8386 8 x 6 x .2 (2.4 x 1.8 x .1) 55 (208.2) 30 (13.6)
8387 10 x 8 x .2 (3 x 2.4 x .1) 88 (333.1) 38 (17.2)
8568 3 x 3 x .3 (.9 x .9 x .1) 22 (83) 20 (9.7)
8570 6 x 4 x .3 (1.8 x 1.2 x .1) 59 (223.3) 27 (12.2)
8571 8 x 8 x .3 (2.4 x 2.4 x .1) 159 (601.9) 45 (20.4)
8572 10 x 10 x .3 (3 x 3 x .1) 249 (942.6) 61 (27.7)
8573 20 x 10 x .3 (6.1 x 3 x .1) 498 (1885.1) 101 (45.8)

Combination Drive Through Berms

Combination drive through secondary containment berms use the aluminum angle and foam wall models to create a convenient, drive-over boundary with large spill capacity. The aluminum brackets create sturdy side walls, while the self-rising foam walls make transport on and off the spill berms easy. Washing a large fleet truck covered in contaminated sediment? Drive it on, do the job, and drive it off – all while staying within secondary containment regulations. Afterward, water can be filtered within the berm or pumped out for safe disposal. Regardless, the drive through berm is ready to work again as the foam walls go back down, allowing another truck to drive onto it.


Part # Dimensions ft. (m) Containment Capacity gal. (L) Weight lbs. (kg)
8500 4 x 6 x 1 (1.2 x 1.8 x .3) 179 (677) 72 (32.7)
8501 10 x 10 (3.0 x 3.0) 748 (2831) 176.0 (79.8)
8502 12 x 26 (3.7 x 7.9) 2,333 (8,831) 189.0 (85.7)
8503 12 x 30 (3.7 x 9.1) 2,692 (10,190) 256.0 (116.1)
8509 12 x 36 x 1 (3.7 x 11 x .3) 3,231 (12,230) 283.0 (128.4)
8505 60 x 12 x 1 (18.3 x 3.7 x .3) 5385 (20384.4) 297.0 (134.5)
8508 14 x 54 x 1 (4.3 x 16.5 x .3) 5,655 (21,406) 368 (166.9)

Spill Berm Downloads

  • Drive Through Spill Containment Berm Selection Guide (PDF)
  • Module Containment Wall Product Document (PDF)
  • Secondary Spill Containment Selection Guide (PDF)
  • Chemical Compatibility Guide (PDF)
  • Ultra Berm Builder Product Data Sheet (PDF)
  • Ultra Berm Builder Instructions (PDF)

    • For pricing or more information about spill berms Contact Us or call us at 863-261-8388.
